TECHNICAL SPECIFICATION
| 1 | Brand | CMH | CMH | |
| 2 | Model | ET20W | ET35W | |
| 3 | Rated Capacety | kg | 2000 | 3500 |
| 4 | Battery | V/AH | 2x12V 100AH | 2x12V 120AH |
| 5 | Charger | V/A | 24V 30A | 24V 30A |
| 6 | Drive Motor | kw | 1.2 | 1.5 |
| 7 | Drive Wheel | mm | 16×6.5-8 | 375×115 |
| 8 | Front Wheel | mm | 2-φ125×50 | 2-φ150×50 |
| 9 | Ground Clearance | mm | 100 | 100 |
| 10 | Height of Top Traction Pin | mm | 731.6 | 844.6 |
| 11 | Height of Rear Traction Pin | mm | 220-400 | 225-360 |
| 12 | Traction Speed | km/h | 4-5 | 2.5-3.5 |
| 13 | Overall Length | mm | 1705 | 1915 |
| 14 | Overall Width | mm | 760 | 805 |
| 15 | Overall Height | mm | 1100 | 1230 |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
