TECHNICAL SPECIFICATION
| Item | Brand | CMH | CMH | |
| 1 | Model | ET10W | ET15W | |
| 2 | Rated Capacety | kg | 1000 | 1500 |
| 3 | Battery | V/AH | 2x12V 70AH | 2x12V 70AH |
| 4 | Charger | V/A | 24V 10A | 36V 10A |
| 5 | Driving Motor | kw | 0.8 | 1.2 |
| 6 | Driving Wheel | mm | 330*127 | 330*127 |
| 7 | Rear Wheel | mm | 100*30 | 100*30 |
| 8 | Balance Wheel | mm | 100*27 | 100*27 |
| 9 | Unload Speed | m/h | 7 | 7 |
| 10 | Load Speed | m/h | 6 | 6 |
| 11 | Load Gradeability | % | 5 | 5 |
| 12 | Unload Gradeability | % | 10 | 10 |
| 13 | Net Weight | kg | 120 | 180 |
| 14 | Overall Size | mm | 790x700x1280 | 850x700x1280 |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
