TECHNICAL SPECIFICATION
| Standard | |||
| 1.1 | Brand | CMH | |
| 1.2 | Model number | ET30C | |
| 1.3 | Power type | Battery | |
| 1.4 | Operation type | Stand-on | |
| 1.5 | Wheelbase | y(mm) | 975 |
| Weight | |||
| 2.1 | Service weight(with battery) | kg | 550 |
| 2.2 | Axle loading, unladen drive/load | kg | 350/200 |
| 2.3 | Battery weight | kg | 200 |
| Wheel | |||
| 3.1 | Tyre,operator/load side | Rubber | |
| 3.2 | Tyre size,drive | mm | Φ215×75 |
| 3.3 | Tyre size,load | mm | Φ150×60 |
| 3.4 | Wheels number, front/back(x=driven) | 1X/2 | |
| 3.5 | Tread, drive | b3(mm) | / |
| 3.6 | Tread, load | b2(mm) | 770 |
| Size | |||
| 4.1 | Overall height | h14 | 1361 |
| 4.2 | Towing coupling height | h10(mm) | 140-240 |
| 4.3 | stand height | h2(mm) | 97 |
| 4.4 | Overall length | l1(mm) | 1238 |
| 4.5 | Overall width | b1(mm) | 850 |
| 4.6 | Ground clearance, centre of wheelbase |
m2(mm) | 50 |
| 4.7 | Turning radius | Wa(mm) | 1160 |
| Function | |||
| 5.1 | Travel speed,with/without load | km/h | See graph |
| 5.2 | Rated drawbar pull | F(N) | 750 |
| 5.3 | Max. climbing ability,with/without load(S2-5min) |
%(tanθ ) | See graph |
| 5.4 | Service brake | Electromagnetic | |
| Drive | |||
| 6.1 | Drive motor rating(S2-60 min) | kw | 1.5(AC) |
| 6.2 | Battery voltage/rated capacity | V/Ah | 24/210 |
| 6.3 | Steering System | Mechanical | |
| Other | |||
| 7.1 | Battery replaces | Hoisting | |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
