TECHNICAL SPECIFICATION
| 1 | Brand | CMH | CMH | CMH | |
| 2 | Model | HPT20SS | HPT25SS | HPT30SS | |
| 3 | Rated Capacity | kg | 2000 | 2500 | 3000 |
| 4 | Power Supply | Manual | Manual | Manual | |
| 5 | Operating Type | Pedestrian | Pedestrian | Pedestrian | |
| 6 | Fork Width | mm | 540/685 | 540/685 | 540/685 |
| 7 | Fork Length | mm | 1150/1220 | 1150/1220 | 1150/1220 |
| 8 | Min. Fork Height | mm | 85 | 85 | 85 |
| 9 | Max. Fork Height | mm | 200 | 200 | 200 |
| 10 | Front wheel | mm | Φ70*60 | Φ80*70 | Φ80*70 |
| 11 | Steering Wheel | mm | Φ160*50 | Φ180*50 | Φ180*50 |
| 12 | Wheel Type | Nylon/PU/Rubber | Nylon/PU/Rubber | Nylon/PU/Rubber |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
