TECHNICAL SPECIFICATION
| 1 | Brand | CMH | CMH | CMH | CMH | CMH | |
| 2 | Model | SJY0.5-6 | SJY0.5-8 | SJY0.5-10 | SJY0.5-12 | SJY0.5-14 | |
| 3 | Max Platform Height | mm | 6000 | 8000 | 10000 | 12000 | 13800 |
| 4 | Min Platform Height | mm | 1050 | 1175 | 1300 | 1425 | 1439 |
| 5 | Platform Size | mm | 2270×1150 | 2270×1150 | 2270×1150 | 2270×1150 | 2640×1150 |
| 6 | Rated Lift Capacity | kg | 500 | 500 | 500 | 500 | 320 |
| 7 | Extending Legs Dimension | mm | 2700×2200 | 2700×2200 | 2700×2200 | 2700×2200 | 2700×2350 |
| 8 | Lifting Time | s | 50 | 50 | 80 | 80 | 80 |
| 9 | Lifting Motor DC | KW | 2.2 | 2.2 | 3 | 3 | 3 |
| 10 | Voltage DC | V | 24 | 24 | 24 | 24 | 24 |
| 11 | Voltage AC | V | 220 | 220 | 380 | 380 | 380 |
| 12 | Overall Length | mm | 2540 | 2540 | 2540 | 2540 | 2910 |
| 13 | Overall Width | mm | 1300 | 1300 | 1300 | 1300 | 1450 |
| 14 | Overall Height | mm | 1730 | 1855 | 1980 | 2105 | 2110 |
| 15 | Net Weight | kg | 1280 | 1460 | 1870 | 2050 | 2840 |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
