TECHNICAL SPECIFICATION
| 1 | Brand | CMH | CMH | CMH | |
| 2 | Model | FSJY3 | FSJY3.9 | FSJY4.8 | |
| 3 | Rated Lift Capacity | kg | 300 | 300 | 300 |
| 4 | Max Platform Height | mm | 3000 | 3900 | 4800 |
| 5 | Max Work Height | mm | 5000 | 5900 | 6800 |
| 6 | Platform Size | mm | 1170×600 | 1170×600 | 1170×600 |
| 7 | Ground Clearance | mm | 60 | 60 | 60 |
| 8 | Wheel Base | mm | 990 | 990 | 990 |
| 9 | Min Turning Radius | mm | 1200 | 1200 | 1200 |
| 10 | Driving Motor | KW | 2×0.4 | 2×0.4 | 2×0.4 |
| 11 | Lifting Motor | KW | 0.8 | 0.8 | 0.8 |
| 12 | Driving Speed (Platform Stowed) | km/h | 4 | 4 | 4 |
| 13 | Driving Speed (Platform Elevated) | km/h | 0.8 | 0.8 | 0.8 |
| 14 | Lifting Time | sec | 20 | 20 | 20 |
| 15 | Lowering Time | sec | 30 | 30 | 30 |
| 16 | Battery | V/AH | 2x12V 80AH | 2x12V 80AH | 2x12V 80AH |
| 17 | Charger | V/A | 24V 10A | 24V 10A | 24V 10A |
| 18 | Max Gradeability | % | 10-15 | 10-15 | 10-15 |
| 19 | Max Working Angle | degree | 2 | 2 | 2 |
| 20 | Driving Wheel | mm | Φ230×80 | Φ230×80 | Φ230×80 |
| 21 | Front Wheel | mm | Φ150×60 | Φ150×60 | Φ150×60 |
| 22 | Overall Length | mm | 1300 | 1300 | 1300 |
| 23 | Overall Width | mm | 760 | 760 | 760 |
| 24 | Overall Height | mm | 1830 | 1930 | 1990 |
| 25 | Net Weight | kg | 490 | 600 | 760 |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
