TECHNICAL SPECIFICATION
| 1 | Brand | CMH | CMH | CMH | CMH | |
| 2 | Model | FSEP3-2.7 | FSEP3-3.3 | FSEP3-4.0 | FSEP3-4.5 | |
| 3 | Rated Lift Capacity | kg | 300 | 300 | 300 | 300 |
| 4 | Max Platform Height | mm | 2700 | 3300 | 4000 | 4500 |
| 5 | Max Machine Height | mm | 4020 | 4900 | 5310 | 6000 |
| 6 | Ground Clearance | mm | 40 | 40 | 40 | 40 |
| 7 | Platform Size | mm | 600×700 | 600×700 | 600×700 | 600×700 |
| 8 | Max Drive Speed (Stowed) | km/h | 4 | 4 | 4 | 4 |
| 9 | Max Drive Speed (Elevated) | km/h | 1.6 | 1.6 | 1.6 | 1.6 |
| 10 | Min Turning Radius | mm | 1600 | 1600 | 1600 | 1600 |
| 11 | Max Gradeability | % | 15-20 | 15-20 | 15-20 | 15-20 |
| 12 | Drive Wheel Size | mm | φ230X80 | φ230X80 | φ230X80 | φ230X80 |
| 13 | Steering Wheel Size | mm | φ150X40 | φ150X40 | φ150X40 | φ150X40 |
| 14 | Driving Motor | kw | 2×0.4 | 2×0.4 | 2×0.4 | 2×0.4 |
| 15 | Lifting Motor | kw | 1.6 | 1.6 | 1.6 | 1.6 |
| 16 | Battery | V/AH | 2x12V 100AH | 2x12V 100AH | 2x12V 100AH | 2x12V 100AH |
| 17 | Charger | V/A | 24V 15A | 24V 15A | 24V 15A | 24V 15A |
| 18 | Overall Length | mm | 1530 | 1530 | 1620 | 1620 |
| 19 | Overall Width | mm | 760 | 760 | 760 | 760 |
| 20 | Overall Height | mm | 1830 | 2130 | 1840 | 2000 |
| 21 | Net Weight | kg | 430 | 450 | 660 | 680 |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
