TECHNICAL SPECIFICATION
| Performance | ||||
| 1.1 | Brand | CMH | CMH | |
| 1.2 | Model | FB16S | FB20S | |
| 1.3 | Power Type | Battery | Battery | |
| 1.4 | Operate Type | Seated | Seated | |
| 1.5 | Rated Capacity | Q(kg) | 1600 | 2000 |
| 1.6 | Load center | C(mm) | 500 | 500 |
| Tyre & Rim | ||||
| 2.1 | Wheel Type-Front/Rear | Solid tire | Solid tire | |
| 2.2 | Front Wheel | 18×7-8 | 200/50-10 | |
| 2.3 | Rear Wheel | 15×4.5-8 | 15×4.5-8 | |
| 2.4 | Tyres No. -front/rear (X=Drive wheel) | 2X / 2 | 2X / 2 | |
| Dimension | ||||
| 3.1 | Fork Tilt Angle—-Upward/Backward–deg. | α/β(º) | 6/6 | 6/6 |
| 3.2 | Mast Type | Duplex Mast | Duplex Mast | |
| 3.3 | Mast Lowred Height | h1(mm) | 1995 | 1995 |
| 3.4 | Free Lift | h2(mm) | 140 | 140 |
| 3.5 | Lift height | h3(mm) | 3000 | 3000 |
| 3.6 | Mast Extended Height | h4(mm) | 4030 | 4030 |
| 3.7 | Overhead Guard Height | h6(mm) | 2000 | 2000 |
| 3.8 | Seat Height to Ground | h7(mm) | 1055 | 1055 |
| 3.9 | Overall Length | L1(mm) | 3090 | 3090 |
| 3.10 | Length-to Fork Face | L2(mm) | 2020 | 2020 |
| 3.11 | Wheel Base | y(mm) | 1480 | 1480 |
| 3.12 | Front Overhang | x(mm) | 345 | 345 |
| 3.13 | Overall Width | b1(mm) | 1250 | 1250 |
| 3.14 | Tread Front/rear | b10/b11(mm) | 1080/180 | 1050/180 |
| 3.15 | Fork Dimensions | i/e/s(mm) | 1070*100*35 | 1070*100*40 |
| 3.16 | Width of fork carriage | b3(mm) | 1040 | 1040 |
| 3.17 | Forks spread | b5(mm) | 222-1000 | 222-1000 |
| 3.18 | Aisle width for pallet 1000*1200mm across 1200mm | Ast(mm) | 3350 | 3350 |
| 3.19 | Trurning radius | Wa(mm) | 1660 | 1660 |
| Function | ||||
| 4.1 | Travel Speed -laden/unladen | km/h | 12/13 | 12/13 |
| 4.2 | Lift speed-laden/unladen | mm/s | 260/340 | 260/340 |
| 4.3 | Max. Gradeability -laden/unladen | % | 12/14 | 13/15 |
| Power | ||||
| 5.1 | Driving Motor (S2 60) | kw | AC 4.8*2 | AC 4.8*2 |
| 5.2 | Lift Motor (S3 15%) | kw | AC 8.6 | AC 8.6 |
| 5.3 | Battery | V/AH | 48/400 | 48/490 |
| Weight | ||||
| 6.1 | Battery | kg | 645 | 770 |
| 6.2 | Service Weight | kg | 3050 | 3200 |
| Steering & Braking | ||||
| 7.1 | Steering type | Hydraulic | Hydraulic | |
| 7.2 | Parking Brake model | Hydraulic power | Hydraulic power | |
| 7.3 | Parking Operation type | Pedal | Pedal | |
| 7.4 | Service Brake | Hand Brake | Hand Brake | |
CMH® retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
