TECHNICAL SPECIFICATION
| General | 1.1 | Brand | CMH | CMH | CMH | CMH | |
| 1.2 | Model | MC | MC | MC | MC | ||
| Model code | FBRT12 | FBRT12 (SQ) | FBRT16 | FBRT16 (SQ) | |||
| 1.3 | Power Type | Battery | Battery | Battery | Battery | ||
| 1.4 | Driving mode | Standing | Standing | Standing | Standing | ||
| 1.5 | Load capacity | Q(kg) | 1200 | 1200 | 1600 | 1600 | |
| 1.6 | Load Center Distance | C(mm) | 550 | 550 | 600 | 600 | |
| 1.9 | Wheelbase | y(mm) | 1640 | 1640 | 1700 | 1700 | |
| Weight | 2.1 | Service weight (incl.battery) | kg | / | / | / | / |
| 2.2 | Axle loading, laden front/rear | kg | |||||
| 2.3 | Axle loading, unladen front/rear | kg | |||||
| Wheel | 3.1 | Tyre type,front/rear | PU | PU | PU | PU | |
| 3.2 | Tyre size, front | mm | φ140×100 | φ140×100 | φ140×127 | φ140×127 | |
| 3.3 | Tyre size, rear | mm | φ380×165 | φ380×165 | φ380×165 | φ380×165 | |
| 3.4 | Balance wheel size | mm | φ204×76 | φ204×76 | φ204×76 | φ204×76 | |
| 3.5 | Wheels,number front/rear (X=driven) | 4 /1X+2 | 4 /1X+2 | 4 /1X+2 | 4 /1X+2 | ||
| 3.6 | Drive wheelbase | b10(mm) | 1210 | 1210 | 1280 | 1280 | |
| 3.7 | Track width, rear | b11(mm) | 726 | 726 | 726 | 726 | |
| Diension | 4.2 | Mast retracted height | h1(mm) | refer to the mast specification | refer to the mast specification | refer to the mast specification | refer to the mast specification |
| 4.3 | Free lift height | h2(mm) | 0 | refer to the mast specification | 0 | refer to the mast specification | |
| 4.4 | Lift height | h3(mm) | refer to the mast specification | refer to the mast specification | refer to the mast specification | refer to the mast specification | |
| 4.5 | Mast extended height | h4(mm) | refer to the mast specification | refer to the mast specification | refer to the mast specification | refer to the mast specification | |
| 4.7 | Overhead guard height | h6(mm) | 2260/2300 | 2260/2300 | 2260/2300 | 2260/2300 | |
| 4.8 | Platform height, raised | h7(mm) | 355 | 355 | 355 | 355 | |
| 4.19 | Overall length | l1(mm) | 2960 | 2960 | 3000 | 3000 | |
| 4.21 | Overall width | b1(mm) | 1475[1] | 1475[1] | 1575[1] | 1575[1] | |
| 4.22 | Fork dimensions | l/e/s(mm) | 1100/125/50 | 1100/125/50 | 1200/125/50 | 1200/125/50 | |
| 4.23 | Installation class | II-A | II-A | II-A | II-A | ||
| 4.24 | Fork carriage width | b3(mm) | 820 | 820 | 820 | 820 | |
| 4.25 | Fork outside spread | b5(mm) | 765～265 | 765～265 | 765～265 | 765～265 | |
| 4.27 | Width over guide rollers | b6(mm) | 1475 | 1475 | 1575 | 1575 | |
| 4.29 | Side shift distance | b7(mm) | 1180 | 1180 | 1280 | 1280 | |
| 4.32 | Min. ground clearance | m1(mm) | 60 | 60 | 60 | 60 | |
| 4.34.1 | Stacking aisle width pallet to pallet（1100×1100） | Ast(mm) | 1500[2] | 1500[2] | 1600[2] | 1600[2] | |
| 4.34.2 | Stacking aisle width pallet to pallet（1200×1200） | Ast(mm) | 1600[2] | 1600[2] | 1600[2] | 1600[2] | |
| 4.35 | Turning radius | Wa(mm) | 1910 | 1910 | 1980 | 1980 | |
| 4.38 | Center of axle to fork pivot | l8(mm) | 675 | 675 | 645 | 645 | |
| Main aisle width | Wa(mm) | ≥(3350+350)[3] | ≥(3350+350)[3] | ≥(3450+350)[3] | ≥(3450+350)[3] | ||
| Performance | 5.1 | Travelling speed, laden/unladen | km/h | 7.5/8 | 7.5/8 | 7.5/8 | 7.5/8 |
| 5.2 | Lift speed, laden/unladenload | mm/s | 300/300 | 300/300 | 300/300 | 300/300 | |
| 5.3 | Lowering speed, laden/unladen | mm/s | 340/340 | 340/340 | 340/340 | 340/340 | |
| 5.8 | Gradeability, laden/unladen | %(tanθ ) | 5/8 | 5/8 | 5/8 | 5/8 | |
| 5.10.1 | Service brake | Mechanical/Regenerative | Mechanical/Regenerative | Mechanical/Regenerative | Mechanical/Regenerative | ||
| 5.10.2 | Parking brake | Mechanical | Mechanical | Mechanical | Mechanical | Mechanical | |
| Elecrical | 6.1 | Drive motor, rating S2=60 | kw | 5.5 AC | 5.5 AC | 5.5 AC | 5.5 AC |
| 6.2 | Lift motor, rating S3=15% | kw | 15 AC | 15 AC | 15 AC | 15 AC | |
| 6.4 | Battery voltage/nominal capacity | V/Ah | 48/390[4] | 48/390[4] | 48/480[4] | 48/480[4] | |
| 6.5 | Battery weight | kg | 618 | 618 | 726 | 726 | |
| Others | Battery replacement method | Side-pull | Side-pull | Side-pull | Side-pull | ||
| Steering system | Electric Steering | Electric Steering | Electric Steering | Electric Steering | |||
