TECHNICAL SPECIFICATION
| Item | Brand | CMH | CMH | CMH | |
| 1 | Model | AWP6-1000 | AWP8-1000 | AWP10-1000 | |
| 2 | Max Platform Height | mm | 6000 | 8000 | 10000 |
| 3 | Working Height | mm | 7700 | 9700 | 11700 |
| 4 | Ground Clearance | mm | 80 | 80 | 80 |
| 5 | Lift Rated Capacity | kg | 150 | 125 | 125 |
| 6 | Platform Size | mm | 650×600 | 650×600 | 650×600 |
| 7 | Outspread Size | mm | 1930×1770 | 1930×1770 | 1930×1770 |
| 8 | Electrical Source AC | V | 220 | 220 | 220 |
| 9 | Electrical Source DC | V | 24 | 24 | 24 |
| 10 | Battery | V/AH | 2x12V 60AH | 2x12V 60AH | 2x12V 60AH |
| 11 | Charger | V/A | 24V 10A | 24V 10A | 24V 10A |
| 12 | Lifting Motor AC | KW | 0.75 | 0.75 | 0.75 |
| 13 | Lifting Motor DC | KW | 1.2 | 1.2 | 1.2 |
| 14 | Overall Length | mm | 1330 | 1330 | 1330 |
| 15 | Overall Width | mm | 800 | 800 | 800 |
| 16 | Overall Height | mm | 1950 | 2050 | 2150 |
| 17 | Net Weight AC | kg | 300 | 350 | 400 |
| 18 | Net Weight DC | kg | 330 | 380 | 430 |
CMH retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
