TECHNICAL SPECIFICATION
| 1 | Brand | CMH | CMH | CMH | |
| 2 | Model | HPT20 | HPT25 | HPT30 | |
| 3 | Rated Capacity | kg | 2000 | 2500 | 3000 |
| 4 | Power Type | Manual | Manual | Manual | |
| 5 | Operating Type | Pedestrian | Pedestrian | Pedestrian | |
| 6 | Fork Width | mm | 550/685 | 550/685 | 550/685 |
| 7 | Fork Length | mm | 1150/1200 | 1150/1200 | 1150/1200 |
| 8 | Fork Size | mm | 160×52 | 160×52 | 160×52 |
| 9 | Min. Fork Height | mm | 75 | 75 | 75 |
| 10 | Max. Fork Height | mm | 190 | 190 | 190 |
| 11 | Overall Height | mm | 1220 | 1220 | 1220 |
| 12 | Overall Length | mm | 1540/1610 | 1540/1610 | 1540/1610 |
| 13 | Ground Clearance | mm | 26 | 26 | 26 |
| 14 | Front wheel | mm | Φ74*70 | Φ74*70 | Φ74*70 |
| 15 | Steering Wheel | mm | Φ180*50 | Φ180*50 | Φ180*50 |
| 16 | Tread width, steer | mm | 128 | 128 | 128 |
| 17 | Tread width, load | mm | 190/520 | 190/520 | 190/520 |
| 18 | Wheel Type | Nylon/PU/Rubber | Nylon/PU/Rubber | Nylon/PU/Rubber | |
| 19 | Self Weight | kg | 60 | 65 | 70 |
| 20 | Identification Code | BF | BF | BF |
CMH retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
