TECHNICAL SPECIFICATION
| General | 1 | Brand | CMH | CMH | CMH | |
| 2 | Model | EOP15 | EOP15 | EOP15 | ||
| 3 | Power Type | Battery | Battery | Battery | ||
| 4 | Rated Load Capacity | Q(kg) | 1500 | 1500 | 1500 | |
| 5 | Load Centre | c(mm) | 600 | 600 | 600 | |
| 6 | Load Distance, center of drive axle to fork | x(mm) | 206 | 206 | 206 | |
| Wheel | 7 | Tyre size, frot | mm | 310×125 | 310×125 | 310×125 |
| 8 | Tyre size, rear | mm | 128×73 | 128×73 | 128×73 | |
| 9 | Aditional wheel | mm | 150×47 | 150×47 | 150×47 | |
| 10 | Wheels, numer of front rar (x=driven wheel) | 1x+2/4 | 1x+2/4 | 1x+2/4 | ||
| Characteristic & Dimension | 11 | Height, mast lowered | h1(mm) | 2410 | 3080 | 3750 |
| 12 | Max. lift height | h3(mm) | 5000 | 7000 | 9000 | |
| 13 | Height, mast extended | h4(mm) | 7230 | 9230 | 11230 | |
| 14 | Height of platform | h7(mm) | 230 | 230 | 230 | |
| 15 | Lowered height | h13(mm) | 80 | 80 | 80 | |
| 16 | Overall length | l1(mm) | 3200 | 3200 | 3200 | |
| 17 | Coupling height | l2(mm) | 1975 | 1975 | 1975 | |
| 18 | Overall width | b1/b2(mm) | 1100/1352 | 1100/1352 | 1100/1352 | |
| 19 | Forks length | s/e/l(mm) | 45x100x1220 | 45x100x1220 | 45x100x1220 | |
| 20 | Width overall forks | b5(mm) | 530/715 | 530/715 | 530/715 | |
| 21 | Height of overhead guard | h6(mm) | 2290 | 2290 | 2290 | |
| Performance | 22 | Aisle width for pallets 1000×2000 crossway | Ast(mm) | 1400 | 1400 | 1400 |
| 23 | Aisle width for pallets 800×2000 lengthway | Ast(mm) | 1400 | 1400 | 1400 | |
| 24 | Turning radius | Wa(mm) | 1800 | 1800 | 1800 | |
| 25 | Travel speed, laden/unladen | km/h | 7.7/8 | 7.7/8 | 7.7/8 | |
| 26 | Lift speed, laden/unladen | mm/s | 0-0.15/0-0.28 | 0-0.15/0-0.28 | 0-0.15/0-0.28 | |
| 27 | Lowing speed, laden/unladen | mm/s | 0-0.28/0-0.30 | 0-0.28/0-0.30 | 0-0.28/0-0.30 | |
| Battery | 28 | Battery voltage, nominalcapacity K5 | V/Ah | 24/770 | 24/770 | 24/1100 |
| 29 | Battery weight | kg | 610 | 610 | 850 | |
| 30 | Battery dimension, l/w/h | mm | 982x397x561 | 982x397x561 | 982x397x561 | |
| 31 | Service weight, with battery | kg | 3870 | 3870 | 3870 |
CMH retains the right to adjust the specification and configurations to improve the performance without notice, please contact us at info@cmhlift.com to get the newest information.
